APHPM-210 Automatic Horizontal Fill Seal Machine for Pre-Made Pouch
30
Bags / Min
12-250
mL Fill Range
2.8
kW Power
2.8
kW Power
Engineering Advantages
Built for Demanding Production Lines
Fully Automatic End-to-End
Bag feeding, positioning, quantitative filling, N₂ flushing, bag cleaning, cap sorting, capping and withdrawal – zero manual intervention required/
304 stainless steel construction
Variable Frequency Drive
PLC + 10″ Touch Screen HMI
CIP Cleaning System Ready
Modular & Configurable
Industries & Products
Suitable Appplications
Engineered for a wide range of liquid and semi-liquid products across food, beverage and industrial packaging.
How It Works
8-Step Automated Process
From empty bag to sealed, capped product — every step fully automated in one continuous rotary flow.
| Model No. | AP-6BT-XL |
| Pouch Size (Length) | 200–550mm |
| Pouch Size (Width) | 200–400mm |
| Speed | 10–30 pcs/min |
| Voltage | 380V / 3 Phase, 50Hz |
| Power | 4.7 kW |
| Air Consumption | 100 L/min |
| Overall Dimension | L3178 × W2268 × H1966mm |
| Voltage | 3Ph 380V / 3Ph 220V |
| Total Power | 2.8 kW |
| Machine Size (L×W×H) | 2528 × 2347 × 1947 mm |
| Filling Volume Range | 10 – 250 mL |
| Bag Length Range | 10 – 250 mm |
| Bag Width Range | 10 – 145 mm |
| Package Types | Premade Bags with Spout · Doypack with Spout · Shaped Doypack |
| Applications | Coffee · Dairy · Juice · Edible Oil · Jelly · Condiments · Detergentsz |
How It Works
8-Step Automated Process
From empty bag to sealed, capped product — every step fully automated in one continuous rotary flow.
-
Bag Feeding
Automatic magazine bag pick-up & transfer -
Positioning
Precise rotary station alignment -
Quantitative Filling
Dual head accurate metered fill -
N₂ Flushing
Optional oxygen displacement
-
Bag Cleaning
Spout mouth cleaning before cap -
Cap Sorting
Auto cap feed, orient & sort -
Capping
Secure torque-controlled sealing -
Discharge
Auto withdrawal & level control
